 By installing kick braces. These braces keep panels square and supported during installation.

 Your live load requirements will determine stair system length.

 Our ECOP1-240 floor panel can span 32,92m’ without support and carry a live load of 35PSI.

 By installing minimum 6mm rebar every 600 cm on both sides of the panel prior to shot crete application. Rebar must be embedded into slab or bored and epoxied..

  Typically, our production cycle (from date of deposit/PO execution to complete panels loaded on a truck) is 8 weeks. When working with your account executive, please inquire about our current lead times.

 Concrete anchors, furring strips, or metal studs connected to wire pre-plaster or concrete screws can be used, according to manufacturer’s instructions.

 Build time will vary according to the design of your home. The ECO Panel Building System is comprised of only two raw materials (galvanized steel and polystyrene) combined into one unit. Erecting ECO Panel panels is much quicker than building using concrete, bricks, Steel Structures, Steel Cladding , wood studs, exterior sheathing, house wrap, insulation, & sheetrock.

 All panels & wire mesh are included in your order. Shotcrete, rebar, rebar ties, and required supports are not included. These items should be purchased separately.

 Absolutely! Our wall panels can sustain axial loads of 16,180 lbs (ECOP-80 – 150 mm wall thickness).

 A crew can be trained to install ECO Panel Building System Panels in a few hours. The application of shot crete takes skilled laborers and specialized equipment.

 A 4-person crew can install the Vero Building System on an average 197 sqm home. Add approximately 2 people per additional 1,000 sq ft.

 We provide unlimited online training and guidance for the entirety of your build.

 Window and door “bucks” should be used to keep openings perfectly square prior to the shot crete application. These “bucks” can be secured by mechanical fasteners driven through the face and into the EPS core. Shot crete application will keep these in place for the life of your structure.

 No certification is required to install ECO Building System Panels. The application of shot crete might be regulated by your local Council's builders licensing division. NHBRC.

 Electrical wire, conduit, and plumbing are run between the EPS and the welded wire mesh grid. For easier access, use a heat gun to evaporate the EPS. For larger diameter pipes (such as water main or drain), we recommend cutting the wire mesh to gain more access and replacing it with supplied flat mesh.

ECO Panel Building Systems curved panels are manufactured to order using our patented radius equipment.

 Buildings constructed using ECO panels can be completed in a variety of finishes or can be painted traditionally on smoothed plaster. The surface of the walls has the appearance of a thin sheet of reinforced plaster that can easily accommodate all types of wall coverings, including brick, timber clad, stone tiles, and rain screen cladding. If drywall is preferred, our steel stud mounts can be applied prior to shot crete every 16”.

 Traditional foundations can be used and should be based on engineering specifications unique to your area and structure. Vero Building System Panels are connected to the foundation using 450mm long 8mm rebar on each side and staggered every 300 mm Rebar can be “stubbed” in and then foundation poured or you can drill into foundation and use an epoxy rebar anchoring system.

 Yes, you can use most any building material that can be screwed or anchored to concrete with our panels.

 Walls can be added to previously constructed SCIP panels by adding rebar to slab and adjoining wall. Rebar must attach to new panels as detailed in our installation instructions. Previously constructed walls can be trimmed in length or openings cut for windows/doors by using a concrete saw and finishing cut edge as detailed in our installation instructions.

 Using additional rebar and concrete. A diagram for your specific attachment will be shipped with your order.

 ECO panels arrive covered. If covers are removed, panels should be strapped to the pallet to eliminate movement from wind gusts. EPS exposed to sunlight over long periods will discolor. Panels should be kept clean and protected until erected and covered with shotcrete.

 Yes, our panels can be used as partition, curtain, and parapet walls.

 Yes, our panels work great for basements. A waterproof membrane or coating must be used to protect against moisture seepage.

  It is recommended to build the entire structure then apply shot crete.
